ufo::TruncatingEquispacedBinSelector Class Reference

Represents a finite set of consecutive intervals (bins) of the same width, each closed from the left and open from the right. More...

#include <TruncatingEquispacedBinSelector.h>

Inheritance diagram for ufo::TruncatingEquispacedBinSelector:

Collaboration diagram for ufo::TruncatingEquispacedBinSelector:

Public Types
typedef float	ValueType
typedef int	IndexType
Public Types inherited from ufo::EquispacedBinSelectorBase
typedef float	ValueType
typedef int	IndexType

Public Member Functions
	TruncatingEquispacedBinSelector (ValueType lowerBound, ValueType upperBound, IndexType numBins)
	Partition the interval [lowerBound, upperBound) into numBins bins of the same width. More...
IndexType	bin (ValueType value) const override
	Return the index of the bin containing value, or the nearest bin if value lies outside all bins. More...
boost::optional< IndexType >	numBins () const override
	Return the number of bins or boost::none if the bin collection is infinite. More...
ValueType	binWidth () const override
	Return the width of each bin. More...
ValueType	inverseBinWidth () const override
	Return the inverse of the width of each bin. More...
ValueType	binCenter (IndexType bin) const override
	Return the value lying at the center of the bin with index bin. More...
Public Member Functions inherited from ufo::EquispacedBinSelectorBase
virtual	~EquispacedBinSelectorBase ()

Private Attributes
ValueType	lowerBound_
ValueType	binWidth_
ValueType	inverseBinWidth_
IndexType	numBins_

Detailed Description

Represents a finite set of consecutive intervals (bins) of the same width, each closed from the left and open from the right.

Call the bin() function to find the bin containing a particular value.

Definition at line 23 of file TruncatingEquispacedBinSelector.h.

Member Typedef Documentation

IndexType

typedef int ufo::TruncatingEquispacedBinSelector::IndexType

Definition at line 27 of file TruncatingEquispacedBinSelector.h.

ValueType

typedef float ufo::TruncatingEquispacedBinSelector::ValueType

Definition at line 26 of file TruncatingEquispacedBinSelector.h.

Constructor & Destructor Documentation

TruncatingEquispacedBinSelector()

ufo::TruncatingEquispacedBinSelector::TruncatingEquispacedBinSelector ( ValueType  lowerBound, ValueType  upperBound, IndexType  numBins  )

inline

Partition the interval [lowerBound, upperBound) into numBins bins of the same width.

Definition at line 31 of file TruncatingEquispacedBinSelector.h.

Here is the call graph for this function:

Member Function Documentation

bin()

IndexType ufo::TruncatingEquispacedBinSelector::bin ( ValueType  value ) const

inlineoverridevirtual

Return the index of the bin containing value, or the nearest bin if value lies outside all bins.

Implements ufo::EquispacedBinSelectorBase.

Definition at line 41 of file TruncatingEquispacedBinSelector.h.

Here is the caller graph for this function:

binCenter()

ValueType ufo::TruncatingEquispacedBinSelector::binCenter ( IndexType  bin ) const

inlineoverridevirtual

Return the value lying at the center of the bin with index bin.

Implements ufo::EquispacedBinSelectorBase.

Definition at line 60 of file TruncatingEquispacedBinSelector.h.

Here is the call graph for this function:

Here is the caller graph for this function:

binWidth()

ValueType ufo::TruncatingEquispacedBinSelector::binWidth ( ) const

inlineoverridevirtual

Return the width of each bin.

Implements ufo::EquispacedBinSelectorBase.

Definition at line 52 of file TruncatingEquispacedBinSelector.h.

Here is the caller graph for this function:

inverseBinWidth()

ValueType ufo::TruncatingEquispacedBinSelector::inverseBinWidth ( ) const

inlineoverridevirtual

Return the inverse of the width of each bin.

Implements ufo::EquispacedBinSelectorBase.

Definition at line 56 of file TruncatingEquispacedBinSelector.h.

Here is the caller graph for this function:

numBins()

boost::optional<IndexType> ufo::TruncatingEquispacedBinSelector::numBins ( ) const

inlineoverridevirtual

Return the number of bins or boost::none if the bin collection is infinite.

Implements ufo::EquispacedBinSelectorBase.

Definition at line 48 of file TruncatingEquispacedBinSelector.h.

Here is the caller graph for this function:

Member Data Documentation

binWidth_

ValueType ufo::TruncatingEquispacedBinSelector::binWidth_

private

Definition at line 66 of file TruncatingEquispacedBinSelector.h.

inverseBinWidth_

ValueType ufo::TruncatingEquispacedBinSelector::inverseBinWidth_

private

Definition at line 67 of file TruncatingEquispacedBinSelector.h.

lowerBound_

ValueType ufo::TruncatingEquispacedBinSelector::lowerBound_

private

Definition at line 65 of file TruncatingEquispacedBinSelector.h.

numBins_

IndexType ufo::TruncatingEquispacedBinSelector::numBins_

private

Definition at line 68 of file TruncatingEquispacedBinSelector.h.

---

The documentation for this class was generated from the following file:

• TruncatingEquispacedBinSelector.h
