Function to calculate surface relative humidity observation value adjusted from station height to model surface height. Outputs a derived 2m relative humidity adjusted to the model surface height. Observed relative humidity is adjusted from station level to model surface using an empirical vertical gradient LRH = -0.01 %/m. The adjusted humidity value is then constrained to lie between zero and supersaturation with respect to liquid water. More...

#include <ModelHeightAdjustedRelativeHumidity.h>

Inheritance diagram for ufo::ModelHeightAdjustedRelativeHumidity:

[legend]

Collaboration diagram for ufo::ModelHeightAdjustedRelativeHumidity:

[legend]

Public Member Functions
	ModelHeightAdjustedRelativeHumidity (const eckit::LocalConfiguration &=eckit::LocalConfiguration())

void	compute (const ObsFilterData &, ioda::ObsDataVector< float > &) const
	compute the result of the function More...

const ufo::Variables &	requiredVariables () const
	geovals required to compute the function More...

Public Member Functions inherited from ufo::ObsFunctionBase< float >
	ObsFunctionBase (const eckit::LocalConfiguration conf=eckit::LocalConfiguration())

virtual	~ObsFunctionBase ()

Private Attributes
ModelHeightAdjustedRelativeHumidityParameters	parameters_

ufo::Variables	invars_

Additional Inherited Members
Public Types inherited from ufo::ObsFunctionBase< float >
typedef float	Value_
	Type of the values produced by the function. More...

Detailed Description

Function to calculate surface relative humidity observation value adjusted from station height to model surface height. Outputs a derived 2m relative humidity adjusted to the model surface height. Observed relative humidity is adjusted from station level to model surface using an empirical vertical gradient LRH = -0.01 %/m. The adjusted humidity value is then constrained to lie between zero and supersaturation with respect to liquid water.

Definition at line 42 of file ModelHeightAdjustedRelativeHumidity.h.

Constructor & Destructor Documentation

◆ ModelHeightAdjustedRelativeHumidity()

ufo::ModelHeightAdjustedRelativeHumidity::ModelHeightAdjustedRelativeHumidity ( const eckit::LocalConfiguration & conf = eckit::LocalConfiguration() )

explicit

Definition at line 25 of file ModelHeightAdjustedRelativeHumidity.cc.
