Outputs a linear combination of variables. More...

#include <ObsFunctionLinearCombination.h>

Inheritance diagram for ufo::LinearCombination:

Collaboration diagram for ufo::LinearCombination:

[legend]

Public Member Functions
	LinearCombination (const eckit::LocalConfiguration &)

	~LinearCombination ()

void	compute (const ObsFilterData &, ioda::ObsDataVector< float > &) const
	compute the result of the function More...

const ufo::Variables &	requiredVariables () const
	geovals required to compute the function More...

Public Member Functions inherited from ufo::ObsFunctionBase< float >
	ObsFunctionBase (const eckit::LocalConfiguration conf=eckit::LocalConfiguration())

virtual	~ObsFunctionBase ()

Private Attributes
LinearCombinationParameters	options_

ufo::Variables	invars_

Additional Inherited Members
Public Types inherited from ufo::ObsFunctionBase< float >
typedef float	Value_
	Type of the values produced by the function. More...

Detailed Description

Outputs a linear combination of variables.

Example 1

obs function: name: LinearCombination@ObsFunction options: variables: [representation_error@GeoVaLs, sea_water_temperature@ObsError] coefs: [0.1, 1.0]

will return 0.1 * representation_error@GeoVaLs + 1.0 * sea_water_temperature@ObsError

Example 2 - multi-channel

obs function: name: LinearCombination@ObsFunction channels: &select_chans 6-15, 18-22 # this line may be needed depending on the filter used options: variables:

name: brightness_temperature@ObsValue channels: *select_chans
name: brightness_temperature@ObsError channels: *select_chans coefs: [1.0, 0.5]

will return 1.0 * brightness_temperature_<channel>@ObsValue + 0.5 * brightness_temperature_<channel>@ObsError

Definition at line 71 of file ObsFunctionLinearCombination.h.
